[GRASS-user] 3D raster color coding

[Francois_Chartier]

Hi,

I have created a 3D raster from soil properties with about 70K points, with a lot of help from the mailing list i must say.
from the copy of the metadata of the 3d raster (below) it would confirm that the 3D raster worked and the grid is populated with data.
I have copied below the r3.colors and assigned ‘aspectcolr’ as a trial. Unfortunately in the Display window nothing shows up, whether in 2D or in 3D view. I do not know what i am doing incorrectly.

Once I am done and able to develop the 3D raster of the soil properties, I will prepare a simple step by step for developing such a raster which may be useful for others.

±---------------------------------------------------------------------------+
| Layer: BHALL_May24v2@Toronto Date: Sun May 27 16:43:46 2018 |
| Mapset: Toronto Login of Creator: Francois Charti |
| Location: Toronto |
| DataBase: C:\Users\Francois Chartier\Documents\grassdata |
| Title: BHALL_May24v2 |
| Units: none |
| Vertical unit: units |

Timestamp: none
Type of Map: raster_3d Number of Categories: 0
Data Type: FCELL
Rows: 90
Columns: 85
Depths: 307
Total Cells: 2348550
Total size: 3180868 Bytes
Number of tiles: 336
Mean tile size: 9466 Bytes
Tile size in memory: 30420 Bytes
Number of tiles in x, y and z: 6, 7, 8
Dimension of a tile in x, y, z: 15, 13, 39
Projection: UTM (zone 17)
N: 4870795 S: 4825715 Res: 500.88888889
E: 651669 W: 609204 Res: 499.58823529
T: 352 B: 45 Res: 1
Range of data: min = -8.99099445 max = 33.89262009
Data Source:
Data Description:
generated by v.vol.rst
Comments:
v.vol.rst input=“BHMat1All_May12@Toronto” wcolumn=“cat” tension=40. \
smooth=0.1 segmax=50 npmin=200 npmax=700 dmin=2 wscale=1.0 zscale=1.\
0 elevation=“BHALL_May24v2”
±---------------------------------------------------------------------------+
(Wed May 30 21:11:59 2018) Command finished (0 sec)

---

(Wed May 30 21:10:02 2018)
r3.colors map=BHALL_May24v2@Toronto color=aspectcolr
Color table for raster3d map BHALL_May24v2@Toronto set to ‘aspectcolr’
(Wed May 30 21:10:03 2018) Command finished (0 sec)
